Product Details:
Payment & Shipping Terms:
|
| Surface: | Mill Finished | Alloy: | 8011 3003 |
|---|---|---|---|
| High Light: | aluminum strips,aluminum strip |
||
High Tensile Strength Aluminium Products Aluminum Tape 5052 5083 5086 5154 5182 5251
Quick Detail:
|
Product name |
alloy |
temper |
thickness(mm) |
width(mm) |
Inner Diameter |
Application |
Processing way |
|
aluminum strip |
1070 1060 1050 1145 1235 1100 1200 3003 8011 |
H18 H26 H14 H24 H22 O |
0.2mm~3.0mm |
10mm~300mm |
75mm,150mm, 300 mm, 505mm |
All kinds of industry aplicaiton |
DC or CC |
Description:
Specifications of Aluminium Strip / Foil :
1. Grade
1000 Series: 1050 1060 1070 1100 1200 1235 etc.
3000 Series: 3003 3004 3005 3102 3104 3105 3A21 etc.
5000 Series: 5005 5052 5083 5086 5154 5182 5251 5754 etc.
6000 Series: 6061 6063 6082 6A02 etc.
7000 Series: 7050 7075 7475 etc.
8000 Series: 8006 8011 8079 etc.
2. Thickness: 0.20mm-320mm
3. Width: 8mm-2400mm
4. Length: 1220 or per customer's request
5. Temper: all tempers, H1X, H2X, H3X, O, HXXX
6. Continuous casting and hot rolled both available
|
Roofing Coil |
|
|||||
|
Alloy |
Temper |
Thickness (mm) |
Width(mm) |
Tensile Strength(Mpa) |
Elongation |
|
|
8011 |
H18/H26 |
0.200~0.400 |
1000~1300 |
140 |
≥1.5% |
|
|
0.401~0.550 |
155 |
≥1.0% |
|
|||
|
0.551~0.800 |
155 |
≥3% |
|
|||
|
3003 |
H26 |
0.200~0.400 |
170.0~210.0 |
≥2.0% |
|
|
|
0.400~0.800 |
≥3.0% |
|
||||
|
|
|
|
|
|
|
|
|
Aluminum Foil Stock |
|
|||||
|
Alloy |
Temper |
Thickness (mm) |
Width(mm) |
Tensile Strength (Mpa) |
Elongation |
|
|
1235 |
H14 |
0.20~0.50 |
900~1250 |
115.0~135.0 |
≥2.0% |
|
|
8011 |
H14 |
0.20~0.50 |
155.0~165.0 |
≥3.0% |
|
|
|
|
|
|
|
|
|
|
|
Decorative Coil/Sheet |
||||||
|
Alloy |
Temper |
Thickness(mm) |
Width(mm) |
Tensile Strength (Mpa) |
Elongation |
T Bend |
|
1100/8011 /3003 |
H16/H18 /H26 |
0.100.50 |
300--1250 |
155~230 |
≥2.0% |
within 2T |
Manufacturing of Aluminium Strip / Foil
Ingot + Master Alloy → Melting → Holding Fumace → Continuous Casting → Cold Rolling(Mediate Annealing) → Horizontal shear → Annealing → Aluminum Sheet
Applications of Aluminium Strip / Foil :
1. Refrigerator
2. Commercial freezer
3. Corrugated roofing making
4. Cable wrap
5. Capacitor
6. PP cap
7. Anti-theft strips
8. Aluminum/plastic composite pipes
9. PS substrates
