| Application:: | Cookware Ect. | Alloy Or Not:: | Alloy |
|---|---|---|---|
| Shape: | Circle | Diameter: | 120mm-1300mm |
| Thickness: | 0.4mm-6.0mm | Brand Name: | Shuanglin Jiate |
| Treatment Of Aluminum Discs:: | Mill Finished | Color: | Metal Silver |
| High Light: | aluminum disc,aluminum disk |
||
1050 1060 3003 DC / CC Aluminium Disc Cookware Utensils Basin Aluminum Disk/Circle with thickness 0.5mm to 3mm
Applications of aluminum discs
Cold Rolling Aluminum Circles are widely used in furnitures like tables. But most aluminum circles clients requested are Deep Drawing Quality Aluminum Circle. These aluminum circle are widely used in kitchenware, cookware, reflector-light etc.
Aluminum Discs Features:
1. Wide range of selection on circles' size including customized shape and size;
2. Excellent deep drawing and spinning quality;
3. RoHS and REACH compliance.
Aluminium circle
Alloy : 1050 1060 3003.
Thickness: 0.5-3.0mm.
Diameter: 120-1300mm.
Temper O H12 H14 H16 H18
Application: cookware utensils, basin etc.
Packing: in seaworthy wooden pallet or case and one ton per package.
Surface: mill finished,clean,bright,mirror,flat,no wholes,no scratches, no oxidation.
|
Alloy |
Temper |
Specification |
|
|
Thickness(mm) |
Diameter(mm) |
||
|
1050,1060,1100,3003 |
O,H12,H14 |
0.40-6.0 |
120-1300 |
|
Temper |
Thickness(mm) |
Tensile Strength |
Elongation% |
Standard |
|
O |
0.36-6 |
60-100 |
MORE THAN 20 |
GB/T91-2002 |
|
H12 |
0.5-6 |
70-120 |
MORE THAN 4 |
|
|
H14 |
0.5-6 |
85-120 |
MORE THAN 2 |
Parameters:
| Division | Description | Application | Feature |
| 1000 SERIES | 1050 1060 1070 1090 1100 1235representative series aluminum plate is also known as pure aluminum, in the series in 1xxx series belongs to all the alumina quantity of a maximum number of series. Purity can achieve 99.00% above. | Utensil, decoration, Reflecting plate, printing plate, heatproof plate,cookware | Easy to process and weld,resistant to rust,high,conductibility of electricity and heat,low strength |
| 3000 SERIES | 3xxx series aluminum represents 3003 3004,3005, 3 A21 primarily. And can be called in the 3xxx series aluminum antirust aluminum production process more outstanding. The 3xxx series aluminum plate is by manganese as the main component. Content at 1.0-1.5 between. Is a rust-proof function better series. Conventional application in the air conditioning, the refrigerator, such as car in damp environment | Utensil(F/P, inside of rice cooker), aluminum can,material for interior and exterior of building,chemical equipment,Cellular Phone | 20% higher strength than the 1100 series, easily welded and brazed, good antirust,ability Non-heat treatable |
| 5000 SERIES | 5xxx series representatives 5052 5005 5083,5754. The 5000 series aluminum alloy aluminum belong to the more commonly used series, the main elements for magnesium, with magnesium in the amount between 3-5%. And can be called aluminum magnesium alloy. Key features for low density, high tensile strength, elongation rate is high. In the same area under the weight of the magnesium alloy aluminum less than other series. | Ship board heatproof apparatus, material for interior and exterior of building, Parts of Electronic tools.Automobile Components | Excellent corrosion resistance andweld ability together with Easy to process and weld and superior hardness &heatproof Can be anodized for increased corrosion resistance |
| 6000 SERIES | 6xxx series represents 6061 mainly contain magnesium and silicon of two elements, so focused on the 4000 series and the advantages of the 5000 series 6061 is a cold treatment aluminum forging products, apply to fight against corrosion, oxidizing demanding applications. | IT equipment & facility, Mould material, motor material, automatic line, machine & plant etc |
Easy to process , good corrosion resistance, high toughness and processed without distortion after heat-treatable, superior surface treatment |
